Antioxidant Vibrating Fluid Bed Drying Machine
Payment Type: | L/C,T/T |
---|---|
Terms of Trade: | FOB,CIF |
Min. Order: | 1 Set/Sets |
Delivery Time: | 30 Days |
Packaging: | wooden cases |
---|---|
Productivity: | 200-1000kg/h |
Brand: | yuzhou |
Transportation: | Ocean |
Place of Origin: | china |
Supply Ability: | 5-10 set/month |
Certificate: | ISO9001 |
Port: | Shanghai |
Basic Info
Model No.: ZDG
Product Description
Antioxidant Vibrating Fluid Bed Drying Machine
ZDG Antioxidant Vibrating Fluid Bed Drying Machine Features
1. The vibration motor has the advantages of smooth running, low noise and long service life.
2. The material thickness, movement speed, and total amplitude can be steplessly adjusted.
3. As our drying equipment causes little damage to material surface, it is ideal for drying of fragile materials.
4. Thanks to its totally enclosed structure, ZDG Antioxidant Drying Machine prevents cross pollution between materials and air, resulting in a clean working environment.
5. This Antioxidant Drying Machine uses 30 ~ 40% less energy than common drying devices.
Application
ZDG Vibrating fluid bed dryer can be widely used in drying and cooling the materials in the pharmaceutical, food, nourishment, chemical, pesticide, plastic, grain and oil, slag, salt manufacturing, sugar and other industries. The materials include all kinds of additives, chicken powder, gourmet powder, granulated sugar, salt, mineral powder, dispersing agent and so on.
Technical Specifications of Antioxidant Vibrating Fluid Bed Drying Machine
Model | Fluid bed area (m2) | Inlet air temperature(℃) | Outlet air temperature (℃) | Water evaporation capacity (kg/h) | Vibration motor | |
Model | Power (kw) | |||||
ZDG3×0.3 | 0.9 | 70 ~ 140 | 40 ~ 70 | 20 ~ 35 | YZS8-6 | 0.75×2 |
ZDG4.5×0.3 | 1.35 | 70 ~ 140 | 40 ~ 70 | 35 ~ 50 | YZS10-6 | 0.75×2 |
ZDG4.5×0.45 | 0.025 | 70 ~ 140 | 40 ~ 70 | 50 ~ 70 | YZS15-6 | 1.1×2 |
ZDG4.5×0.60 | 0.7 | 70 ~ 140 | 40 ~ 70 | 70 ~ 90 | YZS15-6 | 1.1×2 |
ZDG6×0.45 | 0.7 | 70 ~ 140 | 40 ~ 70 | 80 ~ 100 | YZS15-6 | 1.1×2 |
ZDG6×0.6 | 3.6 | 70 ~ 140 | 40 ~ 70 | 100 ~ 130 | YZS20-6 | 1.5×2 |
ZDG6×0.75 | 4.5 | 70 ~ 140 | 40 ~ 70 | 120 ~ 170 | YZS20-6 | 1.5×2 |
ZDG6-0.9 | 5.4 | 70 ~ 140 | 40 ~ 70 | 140 ~ 170 | YZS30-6 | 2.2×2 |
ZDG7.5×0.6 | 4.5 | 70 ~ 140 | 40 ~ 70 | 130 ~ 150 | YZS30-6 | 2.2×2 |
ZDG7.5×0.75 | 5.625 | 70 ~ 140 | 40 ~ 70 | 150 ~ 180 | YZS40-6 | 3.0×2 |
ZDG7.5×0.9 | 6.75 | 70 ~ 140 | 40 ~ 70 | 160 ~ 210 | YZS40-6 | 3.0×2 |
ZDG7.5×1.2 | 9.0 | 70 ~ 140 | 40 ~ 70 | 200 ~ 280 | YZS50-6 | 3.7×2 |
ZDG7.5×1.5 | 11.25 | 70 ~ 140 | 40 ~ 70 | 230 ~ 330 | YZS50-6 | 3.7×2 |
ZDG8×1.8 | 14.4 | 70 ~ 140 | 40 ~ 70 | 290 ~ 420 | YZS75-6 | 5.5×2 |
